Volume users can OEM, customized your company label information

In compliance with European standard pressure loss safety protection, with buzzer, safety key included

Stable, reliable, convenient design, widely used in dual – speed, multi-functional applications

A4-8+2 :8 Single-speed buttons &Double speed button+2 rotary switches

Adjustable: key function, character mark, rotary switch, explosion-proof, boot mode, automatic shutdown, etc



LED indicator status: operation indicator, low power yellow light is always on

Size: 180 * 60 * 52 mm

Weight: about 220g

Antenna: built in

Key, emergency stop: compact, mushroom head type

Enclosure, protection class: engineering plastics, IP65

Battery: gold-plated 850mAh lithium battery

Charging time: 50 minutes

Continuous operation: 80 hours

Frequency bands: 310-340mhz, 415-450mhz, 850-886mhz

Working temperature range – 35 ° ~ + 85 ℃

Receiving system:

LED indicator light status: visible status display

Emergency stop: double relay (some machines)

Size: 200 * 153 * 56 mm

Weight: about 600g

Alarm bell: 95 db

Antenna: built in — cannot be installed in the sealed metal control cabinet (external: such as in explosion proof)

Enclosure, protection class: engineering plastics, IP65

Relay capacity: fully sealed 10A/250V

Power supply: dc12v-48v, AC36V, 48V, 110V, 220V, 380V, part of the adaptive voltage of the machine

Power consumption: 5 w

Working temperature range – 35 ° ~ + 85 ℃

Installation accessories: embedded installation (optional shock absorbing installation)

Cable, terminal: 1.5m, European style (optional quick connector)



Standard wiring diagram cannot be produced due to single or double step certainty
